Tubes and Pipes
Overview
Steel tubes and pipes are essential components in various industries, providing structural support, fluid transport, and durability. They are known for their strength, versatility, and resistance to corrosion, making them suitable for a wide range of applications. With advancements in manufacturing techniques and materials, modern steel tubes and pipes offer enhanced performance, efficiency, and reliability, meeting the diverse needs of industries worldwide.
Features
- Strength and Durability
- Versatility
- Corrosion Resistance
- High Heat resistance
- Ease of Installation
Chemical Properties
| Section Type | Grade | Mechanical Properties | Dimensional Tolerance | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| YST | UTS MPa | % of Elongation | Outside dimension | Thickness | Squareness | Corner radius | Weight | |||||
| MPa | MPa | < 25mm | > 25mm | Individual Lengths | On Lot of 10 | |||||||
| RHS/SHS IS : 4923 | YST 210 | 210 | 330 | 12 | 20 | +/-1% with a minimum of +/-0.50 mm | +/-10% | 90 deg. +/-2 deg. | 3t max | L +10%,-8% | +/-7.5% | |
| YST 240 | 240 | 410 | 10 | 15 | On lot of 10 MT +/-7.5% | |||||||
| YST 310 | 310 | 450 | 8 | 10 | M & H +/-10% | |||||||
| CHS IS : 1161 | YST 210 | 210 | 330 | 12 | 20 | OD upto and incl 48.3+0.4/-0.8mm. Over 48.3, +/-1.0% | no limit -10% | NA | NA | L +10%,-8% | L +/-5% | |
| YST 240 | 240 | 410 | 12 | 17 | ||||||||
| YST 310 | 310 | 450 | 12 | 14 | L + 10%, -8% | M & H +/-7.5% | ||||||
